Medium to High Pressure Dual Pump-PEEK, 1 mL/min., 20 MPa

SKU: KP-21-01P

Brand: FLOM

$5,300.00

Qty:

+ -

See other options:

Specifications

Attribute name	Attribute value
Pumphead material	PEEK
Max pressure	20 MPa (2900 psi)
Flow rate range	0.001 - 1.000 mL/min
Flow per stroke	4 µL
Plunger stroke	2 mm
Flow accuracy	< 0.3%
Features	Set volume dispensing
Pressure accuracy	-
Wetted materials	Sapphire, Ruby, PTFE, PCTFE, PFA, ETFE, FFKM, HDPE, PEEK, Stainless steel
Remote control	Input: PUMP ON / OFF, Output: Error signal
Communication	RS232C
Dimensions	144 (H) × 79 (W) × 285 (D) mm, excluding protuberances
Weight	Approx. 4.3 kg
Power	AC100 - 240 V (50/60 Hz) MAX 80 VA

There are application notes for Medium to High Pressure Dual Pump-PEEK, 1 mL/min., 20 MPa.
